PIR Detector MY-389 INFRARED PROBE

PIR Detector MY-389 INFRARED PROBE

$10.00 USD
Go to our Address

Product Name: MY-389 Infrared PIR Motion Detector Probe

  • Wattage (Output):  Power Output: DC 12V (Relay Output)

  • Power Consumption (Operation):  Operating Voltage: DC 9V – 16V

    • Static Current: ≤ 18mA (at DC 12V)

    • Alarm Current: ≤ 20mA

  • Measurements: * Detection Range: 10m – 12m

    • Detection Angle: 110° (Wide Angle)

    • Installation Height: 1.7m – 2.5m

  • Features:  Dual Element Infrared: Features a high-sensitivity dual-element sensor for accurate human motion detection and reduced false alarms.

    • Auto-Temperature Compensation: Automatically adjusts sensitivity based on environmental temperature changes to maintain consistent performance.

    • Anti-White Light Interference: Advanced optical lens design prevents interference from sunlight, car headlights, or bright lamps.

    • Adjustable Pulse Count: Allows for sensitivity customization (1P or 2P) to suit the specific security needs of the room.

    • SMD Technology: Built using Surface Mount Device technology for enhanced stability and resistance against Radio Frequency Interference (RFI).

    • Tamper Protection: Includes a built-in tamper switch that triggers an alarm if the detector cover is opened or removed.
